Radar Fall Detection Sensor: VS373

DATASHEET

VS373 is a Radar Fall Detection Sensor1

that adopts a Millimeter Wave
Radar to capture falling. It provides non-contact person detection through
point cloud data and realizes fall alarms. With a fall detection accuracy
rate of up to 99%, it ensures the safety of users. As a Milesight D2D controller & agent, the VS373 seamlessly
communicates with other Milesight D2D devices, establishing more
connections and paving the way for smoother operations. It can also be
linked with alarm switch to notify the relevant personnel to take
emergency measures. With easy configuration and wireless detection, VS373 can be integrated
with the Milesight LoRaWAN® gateway and Milesight Development
Platform, enabling remote and visual management of all sensor data. VS373 can be used in living rooms, bathrooms, bedrooms, kitchens, hospital wards, care homes, and other spaces where falls may occur.

 Features
 Equipped with Millimeter Wave Radar, it can overcome the adverse effects of light and water
mist, which make it able to penetrate some obstacles
 Equipped with a millimeter-wave MIMO array antenna (24 Transmitters & 22 Receivers), it can
provide higher precision and reliability
 Support continuous 24-hour detection and management capabilities, it does not rely on visible light and can operate stably both day and night

Technology： Millimeter Wave Radar Recognition Rate: Up to 99% (Single Person) Installation Height: 2.3m~3m Radar Transceiver: r 24 Transmitters & 22 Receivers FoV: 140 ° Horizontal, 70 ° Vertical Detection Range: 4m*5m
 Support fall detection with a 99% fall capture rate and less than 1% false alarm rate
2
 Support to add sub region for independent occupancy detection
 Support in-bed detection, leaving the bed within the scheduling time will trigger an alarm
 100% privacy protection, no images will be captured
 Support on-site alarms of buzzer and LED indicator and provide backend reporting of alarm
information, enabling timely notification of any emergency
 Store locally 1, 000 historical records and support retransmission to prevent data loss
 Compliant with standard LoRaWAN® gateways and network servers
 Support Milesight D2D protocol to enable ultra-low latency and direct control without gateways
 Support management via Milesight Development Platform

Description:

Power Supply: DC 5V/ 3A by Type-C Port Equipped with a Millimeter-wave MIMO Array Antenna Support Continuous 24-hour Detection and Management Capabilities Support Fall Detection with a 99% Fall Capture Rate and Less Than 5% False Alarm Rate Support Add Sub Region for Independent Occupancy Detection Support In-bed Detection, Leaving the Bed within the Scheduling Time will Trigger an Alarm 100% Privacy Protection, no Images will be Captured Support On-site Alarms of Buzzer and LED Indicator Advanced Features: Milesight D2D Controller IP65 Rated
